Uncovering the secrets of underfloor heating and the versatility of heating foil technology for ultimate comfort and efficiency...

When choosing underfloor heating, it is very important to pay attention to the technical parameters of such a system. It must be appropriate for the type of flooring and the specifics of the room. Such a system must be easy to install, safe and reliable. One such solution is underfloor heating foil or mats. Find out more about underfloor heating and some popular underfloor heating systems!

– What is underfloor heating? Underfloor heating foil and mats
– How does an underfloor heating system work?
– Underfloor heating foil – one of the thinnest underfloor heating systems
– Foil heating system – what should be included in the set?
– Additional tips for installing the foil heater

Underfloor Heating and Underfloor Heating Foil

What is underfloor heating? Underfloor heating foil and mats

Underfloor heating system is a type of heating that is installed under the floor. Depending on the type of flooring it is installed under, each system will have different performance and efficiency. A very popular solution is easy-to-install electric underfloor heating, which ensures consistent heat distribution in every room.

Such systems can have different sizes to be able to cover the floor in smaller and larger rooms. They can also have different output power. Such systems are controlled by a digital or analogue thermostat.

There are many systems available on the market, but foil heating system and electric foil heating mats are of great interest. Both systems have a similar method of operation, but differ slightly in their application and technical parameters. However, each of them is a low-profile system, so it is placed directly under the floor. Usually only thin polystyrene insulation barrier is used.

Foil heater or heating mat are very effective. They can be used as the main heating source in small rooms. In large rooms, they often function as additional heating, ensuring comfort for users.

This warmup foil heater does not take up additional space in the bathroom. It is also an option that is easier to install and is considered more energy efficient. It also does not require as much preparation as the installation of water heating systems.

The foil heater that is made of a fibre reinforced foil wrapped can also be used in other rooms, connected with a heating cable and managed with a thermostat that allows you to set the temperature.

If you want to learn more about this underfloor heating system (underfloor heating foil and mats), additional information can be found at: http://wetroomsdesign.co.uk/underfloor-heating.

How does the underfloor heating system work?

Electric underfloor heating consists of electrical wires that need to be connected to a power source. If a system dedicated to wet rooms is used, you can choose solutions compatible with appropriate shower trays that have insulating properties. Then all the heat is directed towards the ground. There is no heat loss directed in another direction. Warmup foil mats are luxurious solutions that are easy to install, provide warmth for your feet, can be installed in rooms where traditional underfloor heating systems cannot be mounted, and are compatible with many thermostats available on the market.

Underfloor Heating and Underfloor Heating Foil

Underfloor heating foil – one of the thinnest underfloor heating systems

Foil heater delivers evenly distributed heat thanks to reinforced aluminum foil. This is an effective solution that is a more expensive investment, but very beneficial and practical for many years of use.

Such electric foil can be used to heat rooms where the floor is covered with panels, wooden parquet or laminate. It is a modern, technological, high-quality product that is available in various sizes. Its thickness is only 3 mm, so it is often placed under the floor. The foil itself should be placed on a polystyrene insulating board with a minimum thickness of 6 mm. Why is it so important? This insulating layer serves two functions. Firstly, it prevents heat loss and its transfer in a direction other than towards the floor. Secondly, it is a very good insulator that muffles the sounds made by the floor during use.

Foil heating system – what should be included in the set?

It is very important that the foil heating system assembly kit contains all the necessary elements and parts, without which it will not be able to operate effectively. After purchasing such a set, make sure that nothing is missing. The basic, obligatory parts are foil, connection wires, crimp connections and tools, PP and PVC insulation tape, flexible sensor tube and installation guide.

Additional tips for installing the foil heater

Mats can be used in wet rooms, but the foil system is only used in rooms with dry floors. You must remember to always install this type of heating with a residual current device. It should also be placed only in places where there is no other source of heating, i.e. away from fireplaces, etc. It should not be placed under furniture to avoid local overheating. This foil must be connected to a double insulated cable. Before you install it, you need to make sure that there are no damages or dents on it. The floor covered with the foil must be between 5 and 22 mm thick.
